FLIR Si1-LD Acoustic Camera

FLIR Si1-LD Acoustic Camera

FLIR Si1-LD Acoustic Camera

Enquire About This Product View Product Specification

Industrial Acoustic Imaging Camera for Pressurised Leak Detection.

Key features:

  • Automatically detects compressed air and vacuum leaks from up to 130 meters (427 feet) away.
  • Noise suppression technology ensures uninterrupted use in noisy industrial environments, improving accuracy and usability.
  • Band-pass filter enables manual tuning of the frequency range for precise inspections.
  • Lightweight design enables intuitive, single-handed operation, ideal for fast-paced inspections across large facilities.
  • Touch-screen interface captures high-resolution images with real-time quantifiable leak-rate and cost prediction for prioritising repairs.
  • Seamless reporting options, including online analysis via FLIR Acoustic Viewer and offline reporting with FLIR Thermal Studio software.

Imaging information

Digital Camera 12 MP colour
Camera Field Of View (FOV) 65° diagonal
Video Frame Rate Camera 60 fps / Acoustic image: 30 fps / Screen: 70 fps
Zoom 8x digital zoom
Video Image Resolution 1280 × 720
Acoustic Measurement 96 low-noise MEMS microphones, real-time sound visualisation
Detection Threshold 20 kHz: −5 dB / 35 kHz: 9 dB / 50 kHz: 15 dB / 80 kHz: 41 dB / 100 kHz: 56 dB
Bandwidth 2 kHz to 100 kHz
Directional Resolution From 1° up to 0.125°
Operating Distance From 0.3 m (1.0 ft) up to 130 m (427 ft)
Auto Distance Automatic distance up to 5 m (16.45 ft)
Leak Localisation & Detection Automatic leak recognition including estimated leak size and annual cost
Leak Rate Detection Threshold 0.5 m: 0.004 l/min / 2.5 m: 0.010 l/min / 6.0 m: 0.017 l/min
Frequency Selection No
Supported Gases Compressed air
Mechanical Mode No
SKU: T912537 Categories: ,
